MIL-DTL-24643/34F
TABLE I. Details.
Overall diameter
Military part no.
Number of
Type and size
min.
max.
M24643/34
conductors
(inch)
(inch)
-01UO
LSMS-37
37
0.740
0.800
NOTE: Weight of completed cable shall not exceed 0.060 lb/ft.
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
Conductor resistance (ohms/1000 feet at 25 °C, max.)
5.1
Voltage withstand (volts, root mean square, min.)
Conductor to conductor
2000
Conductor to shield
1000
Insulation resistance (megohms/1000 feet, min.)
Conductor to conductor
2000
Conductor to shield
500
Conductor continuity
No failure
Shield continuity
No failure
Jacket flaws
No failure
Group A:
Visual and dimensional
No failure
Group B:
Thermoset proof test (percent, max.)
Insulation
50
Jacket (when tested at 200 °C)
50
Physicals (unaged)
Insulation (extruded)
Tensile strength (lb/in2, min.)
700
Elongation (percent, min.)
150
Jacket (cable)
Tensile strength (lb/in2, min.)
1300
Elongation (percent, min.)
160
2
