MIL-DTL-24643/24C
TABLE II. Color identification code.
Iron, copper, or chromel leg
Pair number
Constantan or alumel
Base color
Tracer color
1
Red
White
-
2
Red
Black
-
3
Red
Green
-
4
Red
Orange
-
5
Red
Blue
-
6
Red
White
Black
7
Red
White
Green
8
Red
White
Orange
9
Red
White
Blue
10
Red
White
Red
11
Red
Black
White
12
Red
Green
White
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
Voltage withstand (volts, root mean square, min.)
Conductor to conductor
2000
Insulation resistance (megohms/1000 feet, min.)
Conductor to conductor
500
Conductor continuity
No failure
ANSI MC96.1 calibration limits of error:
Types LSTCJX and LSTCJXN
±2.2 °C
Types LSTCKX and LSTCKXN -32 to 530 °F
±4 °C
Types LSTCTX and LSTCTXN
±1 °C
Group A:
Visual and dimensional
No failure
Watertightness Types LSTCJX, LSTCKX, and LSTCTX only
No failure
(see MIL-DTL-24643 for limits of water leakage)
Group B:
Cold bending cable
No failure
Thermoset proof test (percent, max.)
3
