MIL-DTL-24643/23G
TABLE I. Details.
Jacket
Cable overall
Number of
Military part no.
thickness min.
Type and size
diameter
pairs
M24643/23
avg. (inch)
max. (inches)
-01UN
LSTTSU-1-1/2
1-1/2
0.050
0.330
-02UN
LSTTSU-3
3
0.050
0.450
-03UN
LSTTSU-5
5
0.050
0.540
-04UN
LSTTSU-10
10
0.062
0.675
-05UN
LSTTSU-15
15
0.062
0.800
-06UN
LSTTSU-20
20
0.062
0.870
-07UN
LSTTSU-30
30
0.075
1.080
-08UN
LSTTSU-40
40
0.075
1.200
-09UN
LSTTSU-50
50
0.075
1.400
-10UN
LSTTSU-60
60
0.075
1.450
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
Conductor resistance (ohms/1000 feet at 25 °C, max.)
18.60
Voltage withstand (volts, root mean square, min.)
Conductor to conductor
2000
Insulation resistance (megohms/1000 feet, min.)
Conductor to conductor
100
Conductor continuity
No failure
Group A:
Visual and dimensional
No failure
Abrasion resistance (scrapes, min.)
250
Watertightness (see MIL-DTL-24643 for limits of water leakage)
No failure
Crack resistance
No damage
Group B:
Cold bending cable
No failure
Thermoset proof test (percent, max.)
Insulation
50
Jacket (when tested at 200 °C)
50
Drip (95±1 °C)
Zero
2
