MIL-DTL-22759/83A
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited
Table I. Construction details.
Conductor
Finished Wire
Stranding
Diameter
Resistance
Diameter
Weight
at 20° C
1/
Part No.
Wire
(number of
(in.)
(in.)
(lb./1000
(68°F)
Size
strands
Ft)
x AWG
(ohms/ 1000
(Max.)
gauge of
MIN.
MAX.
ft max.)
Min.
Max.
strands)
M22759/83-2 -*
2
665 x 30
0.320
0.340
0.170
0.360
0.380
227.0
M22759/83-1-*
1
817 x 30
0.366
0.380
0.139
0.400
0.420
295.0
M22759/83-01-*
0
1045 x 30
0.395
0.425
0.108
0.442
0.462
351.0
M22759/83-02-*
00
1330 x 30
0.440
0.475
0.085
0.498
0.528
432.0
M22759/83-03-*
000
1665 x 30
0.500
0.540
0.068
0.554
0.584
542.0
M22759/83-04-*
0000
2109 x 30
0.565
0.605
0.054
0.615
0.655
689.0
1/
Part Number: The preferred color is dark green with the color designator 5D. Example: Size 2 dark green -
M22759/83-2-5D. White is an acceptable alternate with a color designator of 9.
1/
Table II.
Wire Insulation materials.
Tape Code
Thickness (Nom)
Material
1
0.0020
0.0005 (FP) / 0.0010 (Polyimide) / 0.0005 (FP)
2
0.0020
FP (Skived)
3
0.0030
FP (Unsintered)
1/
Physical properties of FP tapes (skived and unsintered) shall be in accordance with MIL-W-22759 requirements.
TABLE III. Physical properties of FP/Polyimide/FP Tapes.
Tensile Strength
19,000 lb/in sq. (average minimum)
Tensile Modulus
350,000 lb/in sq. (average minimum)
Elongation
40 percent (average minimum)
Dielectric Strength
4,000 volts/mil (average minimum)
0.0005 FP Layer (bottom)
Distinguishable color (next to conductor)
May be used at manufacturer's option
