MIL-DTL-22759/81A
RATINGS:
Temperature rating: 200° C (392°F) maximum continuous conductor temperature.
Voltage rating: 600 volts (rms.) at sea level
ADDITIONAL REQUIREMENTS:
Wet arc propagation resistance (Test required for initial qualification only): Test in accordance with
MIL-STD-2223 Method 3006. Measure the damage of the bundle along the axis. The wire is acceptable if the
following criteria are met:
1. A minimum of 64 wires pass the dielectric test.
2. Three wires or less fail the dielectric test in any one bundle.
3. Actual damage to the wire is not more than 3 inches in any test bundle.
Dry arc propagation resistance (Test required for initial qualification only): Test in accordance with MIL-STD-2223
Method 3007. Measure the damage of the bundle along the axis. The wire is acceptable if the following criteria are
met:
1. A minimum of 64 wires pass the dielectric test.
2. Three wires or less fail the dielectric test in any one bundle.
3. Actual damage to the wire is not more than 3 inches in any test bundle.
Blocking: 200°C ± 2°C (392°F ± 3.6°F)
Color: In accordance with MIL-STD-104, class 1; except as noted below. White preferred. Conformity of color to
the limits of MIL-STD-104 shall not be required after oven exposure.
Munsell color limits for UV laser markable wire
Color
Hue
Value
Chroma
From
To
From
To
From
To
7
8.5
2.5RN
2.5RN
Black
N/A
N/A
7
8
5PB
7.5B
Blue
4
6
7
9
2.5G
7.5G
Green
2
6
7
8
10RP
5R
Red
4
6
5Y
10Y
Yellow
8
9
4
6
2.5YR
7.5R
Brown
7
9
2
4
10R
2.5YR
Orange
6
7
8
10
2.5P
7.5R
Violet
7
8
4
8
Same as Black
Gray
Same as Black
Same as Black
Color striping or banding durability: 125 cycles (250 strokes), 250 grams weight
Conductor strand adhesion: Required
Continuous lengths: Schedule B
4
