MIL-DTL-22759/80A
RATINGS:
Temperature rating: 150° C (320°F) maximum continuous conductor temperature.
Voltage rating: 600 volts (rms.) at sea level
ADDITIONAL REQUIREMENTS:
Wet arc propagation resistance (Test required for initial qualification only): Test in accordance with
MIL-STD-2223 Method 3006. Measure the damage of the bundle along the axis. The wire is
acceptable if the following criteria are met:
1. A minimum of 64 wires pass the dielectric test.
2. Three wires or less fail the dielectric test in any one bundle.
3. Actual damage to the wire is not more than 3 inches in any test bundle.
Dry arc propagation resistance (Test required for initial qualification only): Test in accordance with
MIL-STD-2223 Method 3007. Measure the damage of the bundle along the axis. The wire is
acceptable if the following criteria are met:
1. A minimum of 64 wires pass the dielectric test.
2. Three wires or less fail the dielectric test in any one bundle.
3. Actual damage to the wire is not more than 3 inches in any test bundle.
Blocking: 200°C ± 2°C (392°F ± 3.6°F)
Color: In accordance with MIL-STD-104, class 1; except as noted below. White preferred. Conformity of color to
the limits of MIL-STD-104 shall not be required after oven exposure.
Munsell color limits for UV laser markable wire
Color
Hue
Value
Chroma
From
To
From
To
From
To
Black
2.5RN
2.5RN
7
8.5
N/A
N/A
Blue
5PB
7.5B
7
8
4
6
Green
2.5G
7.5G
7
9
2
6
Red
10RP
5R
7
8
4
6
Yellow
5Y
10Y
8
9
4
6
Brown
2.5YR
7.5R
7
9
2
4
Orange
10R
2.5YR
6
7
8
10
Violet
2.5P
7.5R
7
8
4
8
Gray
Same as Black
Same as Black
Same as Black
Color striping or banding durability: 125 cycles (250 strokes), 250 grams weight
Conductor strand adhesion: Required
Continuous lengths: Schedule B
