MIL-DTL-17/77D
TABLE II. Description.
Components
Construction details
Inner conductor
Seven strands of tinned, copper wire at .0159 inch each.
Overall diameter: 0.0477 inch ± 0.0020.
Dielectric core
Type A-1: Solid, polyethylene.
Diameter: 0.285 inch ± 0.007.
Outer conductor
Double braid of AWG #34 copper wire.
Diameter: 0.360 inch maximum.
Inner braid
Coverage:
95.4% nominal
Carriers:
24
Ends:
9
6.5 ± 10%
Picks/inch:
Outer braid
Coverage:
93.6% nominal
Carriers:
24
Ends:
8
10.3 ± 10%
Picks/inch:
Jacket
Type IIa: PVC
Diameter: 0.425 inch ± 0.007.
ENGINEERING INFORMATION
Continuous working voltage: 3,700 V rms, maximum.
Operating frequency: 3 GHz, maximum.
Velocity of propagation: 65.9 percent, nominal.
Power rating: See figure 2.
Operating temperature range: -40°C to +85°C.
Inner conductor properties:
DC resistance (maximum at 20°C): 0.66 ohm per 100 feet.
Elongation: 15 percent, minimum.
Tensile strength: Not applicable.
Engineering notes: This cable is useful in general purpose low temperature applications. (See
connector series "N" in accordance with MIL-PRF-39012.) This cable tends to degrade as it ages.
2
