MIL-DTL-17/183C
TABLE I. Description.
Component
Construction
Inner conductor
Nineteen strands of tinned copper wire, each strand .0072 inch diameter.
Overall diameter: .0355 inch ±0.0020
Dielectric core
Type A-1: Solid, polyethylene.
Diameter: .116 inch ±0.004
Outer conductor
Single braid of AWG No. 36, tinned copper wire
Diameter: .145 inch maximum
Alternate
Coverage:
92.8% nominal
Coverage:
94.2% nominal
Carriers:
12
Carriers:
16
Ends:
9
Ends:
7
Picks/inch:
7.7 ±10%
Picks/inch:
10.3 ±10%
Barrier tape
A .001 inch thick polyester tape faced with a .002 inch thick layer of aluminum.
The tape shall be applied with a 50% lap, aluminum face toward the outer
conductor.
Diameter: .155 inch maximum
Jacket
Cross-linked polyolefin
Diameter: .195 inch ±0.004
ENGINEERING INFORMATION
Continuous working voltage: 1,400 V rms, maximum.
Operating frequency: 1GHz, maximum.
Velocity of propagation: 65.9 percent, nominal.
Power rating: See figure 2.
Operating temperature range: -30°C to +85°C.
Inner conductor properties:
DC resistance (maximum at +20°C): 1.48 ohms per 100 feet.
Elongation: 15 percent, minimum.
Engineering note: This cable is useful in general purpose low temperature applications.
(See connector series "TNC", "BNC" and "SMA" in accordance with
MIL-PRF-39012.)
REQUIREMENTS
Dimensions, configuration, and description: See figure 1 and table I.
Environmental and mechanical:
Visual and mechanical examination: Applicable.
