MIL-DTL-17/135E
TABLE I. Description.
Component
Construction
Inner conductor (M17/135-00001 and -00002)
Seven strands of silver-coated copper wire each strand
.0296 inch diameter.
Diameter: .089 inch ±0.001
Inner conductor(M17/135-00003 thru -00006)
Solid silver-coated copper wire diameter.
Diameter: .081 inch ±0.001
Dielectric core
Type A-1: Solid polyethylene
Diameter: .285 inch ± 0.010
Inner shield
Single braid of AWG No. 33 silver-coated copper wire
Diameter: .340 inch maximum
Coverage: 90%, minimum
Carriers: 24
Ends: 7
Picks/inch: 8
Separator tape optional
Interlayer
Type A-1: Solid polyethylene
(M17/135-00001 thru M17/135-00004)
Diameter: .365 inch ± .010
Interlayer
Cross-linked polyolefin
(M17/135-00005 and M17/135-00006)
Diameter: .365 inch ± .010
Outer shield
Single braid of AWG No. 33 silver-coated copper wire
Diameter: .414 inch, maximum
Coverage: 85%, minimum
Carriers: 24
Ends: 8
Picks/inch: 5.11
Separator tape optional
Jacket
Cross-linked polyolefin
M17/135-00005 1/ and M17/135-00006
Diameter: .500 inch ± .010, maximum
Jacket
Type XIII: Polyurthane
M17/135-00001 1/ and M17/135-00002
Diameter: .500 inch ± .010, maximum
Jacket
Type IIIa: Polyethylene
M17/135-00003 1/ and M17/135-00004
Diameter: .500 inch ± .010
1/ Free strippable blocking compound needed where necessary to meet hydrostatic test. The inner shield
may be partially imbedded in the dielectric. Applicable to water blocked cables only.
ENGINEERING INFORMATION
Continuous working voltage: 3,700 V rms, maximum.
Operating frequency: 3 GHz, maximum.
Velocity of propagation: 65.9 percent, nominal.
Power rating: See figure 2.
