MIL-DTL-13486/13D
Dimensions and configuration. See figure 1.
Conductor size. All conductors shall be size 20. See "Construction requirements for conductors"
as specified in MIL-DTL-13486.
Longitudinal shifting. This requirement of MIL-DTL-13486 shall not apply.
Shielding. All shielding shall be electrically connected.
Shielding internal. Internal shielding shall consist of a closely and uniformly woven wire braid
applied directly over the insulated conductors by means of a multiple carrier braider. Each carrier
shall have no less than four strands of .005-inch diameter tinned copper wire. The shielding shall
provide no less than 85% coverage.
Shielding outer. Outer shielding (see figure 1) shall consist of a closely and uniformly woven wire
braid woven by means of a multiple carrier braider. Each carrier shall have no less than eight
strands of .0063-inch diameter tinned copper wire. The shielding shall provide no less than 85%
coverage.
Insulated conductors, identification. See table I.
Part or Identifying Number (PIN): M13486/13-1
Former PIN: 7724579
TABLE I. Color code chart.
Conductor number
Base
Stripe
1
Red
None
2
Red
Black
3
Red
White
4
Red
Green
5
Black
None
6
Black
White
7
Black
Red
8
Black
Green
9
White
None
10
White
Black
11
White
Red
12
White
Green
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
Referenced document. This document references MIL-DTL-13486.
