MIL-DTL-13486/12C
Dimensions and configuration. See figure 1.
Conductor size. All conductors shall be size 14. See "Construction requirements for conductors" as
specified in MIL-DTL-13486.
Insulated conductors, identification. See table I.
Part or Identifying Number (PIN): M13486/12-1
Former part number: 7056686
TABLE I. Color code chart.
Conductor number
Base
Stripe
1
Red
None
2
Red
Black
3
Red
White
4
Red
Green
5
Black
None
6
Black
White
7
Black
Red
8
Black
Green
9
White
None
10
White
Black
11
White
Red
12
White
Green
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
Referenced document. This document references MIL-DTL-13486.
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Navy - SH
DLA - CC
Air Force - 85
DLA - CC
Review activities:
Air Force 71, 84, 99
(Project 6145-2010-013)
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above
using the ASSIST Online database at https://assist.daps.dla.mil.
