MIL-DTL-13486/1D
Part or Identifying Number (PIN): See table I.
Former PIN: See table I.
TABLE I. Cable data.
1/
PIN
Conductor size
Diameter "A" (inch)
Former PIN
M13486/1-1
20
.115 ± .010
None
M13486/1-2
18
.130 ± .010
None
M13486/1-3
16
.135 ± .010
7722204
M13486/1-4
16
.160 ± .010
8690176
M13486/1-5
14
.160 ± .010
7720853
M13486/1-6
14
.235 ± .010
7056679
M13486/1-7
12
.235 ± .010
7056678
M13486/1-8
10
.300 ± .010
None
M13486/1-9
8
.360 ± .010
7056677
M13486/1-10
6
.422 ± .010
7056676
M13486/1-11
4
.485 ± .010
8690175
M13486/1-12
2
.610 ± .010
7056675
M13486/1-14
0
.672 ± .010
7056674
M13486/1-15
00
.730 ± .010
None
M13486/1-17
0000
.865 ± .020
7056674-1
1/ See "Construction requirements for conductors" as specified in MIL-DTL-13486.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
Referenced document. This document references MIL-DTL-13486.
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Army AT
DLA - CC
Navy SH
Air Force - 85
DLA - CC
Review activities:
Army - AR, CR
(Project 6145-2010-008)
Navy - MC
Air Force - 71, 84, 99
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above
using the ASSIST Online database at https://assist.daps.dla.mil.
