MIL-DTL-24643C
A
FLAME
D
LENGTH
B
C
MALE PIPE THREAD
For Burner
PHYSICAL DIMENSIONS
Flame
Male Pipe
A
B
C
D
Lengths
Thd Conn
24"
Flame length plus 3/4"
2"
1-3/16"
1"
1"
FIGURE 8. Style X tubular brass manifold for gas flame test.
