MIL-DTL-3849/11C
Open binder applied over the cabled tinsel wire conductors (optional).
Fillers in accordance with MIL-DTL-3849, if necessary, to make a circular cross section.
Polyamide braid, tight fitting applied over the cabled tinsel conductors. The following details shall
apply:
a. Yarn shall be in accordance with MIL-C-572, type P, form Y.
b. The braid shall be composed of 210 denier/34 filaments yarn, 16 carrier, 2 ends per
carrier, 29 picks per inch.
c. Braid color coded dark red unless otherwise specified in the contract or purchase order
see MIL-DTL-3849.
Jacket - Styrene butadiene rubber (SBR) in accordance with MIL-DTL-3849 applied over the
cabled tinsel wire conductors.
Jacket wall thickness .007 inch (0.18 mm) minimum, .010 inch (0.25 mm) maximum.
Finished outside diameter of cable .102 inch (2.59 mm) minimum, .110 inch (2.79 mm) maximum.
Inspection requirements:
Materials inspection.
Visual and dimensions.
Dielectric withstanding voltage.
Insulation resistance 1,000 megohms per 1,000 feet (305 m) minimum.
Continuity
DC resistance.
Breaking load 50 pounds (22.68 kg) minimum.
Part or Identifying Number (PIN):
M
3849/
11
Detailed specification sheet
Basic specification number
M prefix
3
