MIL-DTL-28830/4D
ATTENUATION
AVERAGE POWER
dB/100 Ft.
(Kilowatts)
10
100
1
10
.1
1
.0 1
.1
1 ,0 0 0
10
1 0 ,0 0 0
10 0
FREQUENCY IN MEGAHERTZ
Standard conditions for average power and attenuation:
For average power:
Frequency
Attenuation
VSWR: 1.0
(MHz)
(dB)
Ambient temperature: 40°C
400
.9
Inner conductor temperature: 100°C
2,000
2.5
For attenuation:
4,000
4.1
VSWR: 1.0
Ambient temperature: 24°C
FIGURE 2. Attenuation and power.
3
