MIL-DTL-28830/3D
Attenuation
Average Power
dB/100 Ft.
(Kilowatts)
10
100
1
10
.1
1
.0 1
.1
1 ,0 0 0
10
1 0 ,0 0 0
100
FREQUENCY IN MEGAHERTZ
Standard conditions for average power and attenuation:
For average power:
Frequency
Attenuation
VSWR: 1.0
(MHz)
(Maximum dB)
Ambient temperature: 40°C
400
1.6
Inner conductor temperature: 100°C
3,000
5.4
For attenuation:
8,000
11.6
VSWR: 1.0
Ambient temperature: 24°C
FIGURE 2. Attenuation and power.
