MIL-DTL-27072/9D
Design and construction:
See figure 1
Number of conductors:
4
105 °C
Temperature rating:
Components:
Basic wire:
M16878/18BHB*** (see table I)
Conductor:
Tinned copper
Primary insulation:
Polyvinyl chloride
Colors:
Black
Green
White
Red
Jacket over insulation:
Polyamide
Color:
Natural
Filler:
Material:
In accordance with MIL-DTL-27072
Lay:
2.0 inches
Cabling:
Not applicable
Binder tape material:
Polyvinyl chloride
Shield:
Material:
Tinned copper
Gauge:
In accordance with MIL-DTL-27072
Braid angle:
20 to 40 degrees
Jacket undershield:
Not applicable
Sheath:
Material:
Polyethylene
Wall thickness:
.040 inch nominal
Tensile strength:
In accordance with MIL-DTL-27072
Ultimate elongation:
In accordance with MIL-DTL-27072
Accelerated aging:
Not applicable
Color:
See MIL-DTL-27072
Finished cable:
See table I
Cold bend:
Mandrel size in accordance with MIL-DTL-27072
Dielectric withstanding voltage:
3,000 V rms
Conductor resistance
In accordance with basic wire specification
TABLE I. Construction data.
Basic wire except color
Finished
1/,2/
M16878/18BHB***
cable
(reference)
diameter
PIN 27072/9
Wire
Nominal
inch (mm)
Number of
Strand size
size
diameter
±10%
strands
(AWG)
inch(mm)
HBKB*
18
7
26
.090(2.29)
.334(8.48)
1/ Asterisks (*) shall be replaced by the appropriate color designator.
2/ Dimensions are in inches. Metric equivalents are given for information only.
