MIL-DTL-27072/79C
Design and construction:
See figure 1
Number of conductor:
7
105 °C
Temperature rating:
Components:
Basic wire:
M16878/17BGB*** (see table I)
Conductor:
Tinned copper
Primary insulation:
Polyvinyl chloride
Colors:
White with black tracer
White with blue tracer
White with brown tracer
White with green tracer
White with orange tracer
White with red tracer
White with yellow tracer
Jacket over Insulation:
Polyamide
Color:
Natural
Filler:
Material:
Polyethylene
Lay:
3.0 inches maximum
Cabling:
Not applicable
Binder tape material:
In accordance with MIL-DTL-27072
Shield:
Not applicable
Jacket undershield:
Not applicable
Sheath:
Material:
Polyvinyl chloride
Wall thickness:
.025 inch nominal
Tensile strength:
In accordance with MIL-DTL-27072
Ultimate elongation:
In accordance with MIL-DTL-27072
Accelerated aging:
In accordance with MIL-DTL-27072
Color:
See MIL-DTL-27072
Finished cable:
See table I
Cold bend:
Mandrel size in accordance with MIL-DTL-27072
Dielectric withstanding voltage:
2,000 V rms
Conductor resistance:
In accordance with base wire specification
TABLE I. Construction data.
Basic wire except color
Finished
1/,2/
M16878/17BGB***
cable
(reference)
diameter
PIN 27072/79
Wire
Nominal
inch(mm)
Number of
Strand size
size
diameter
±10%
strands
(AWG)
inch(mm)
KAAA*
20
7
28
.064(1.63)
.227(5.76)
1/ Asterisks (*) shall be replaced by the appropriate color designator.
2/ Dimensions are in inches. Metric equivalents are given for information only.
2
