INCH-POUND
MIL-DTL-27072/65C
12 March 2012
SUPERSEDING
MIL-DTL-27072/65B
8 December 2000
DETAIL SPECIFICATION SHEET
CABLE, SPECIAL PURPOSE, ELECTRICAL, MULTICONDUCTOR
(10 CONDUCTORS) AND SINGLE SHIELDED,
M27072/65MACA*
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-27072.
REQUIREMENTS:
FILLER
SHEATH POLYVINYL CHLORIDE
WHITE
SHIELD TINNED COPPER
WHITE
RED
ORANGE
TAPE POLYETHYLENE
TEREPHTHALATE
WHITE
GREEN
WHITE
WHITE
WHITE
BLACK
BLACK
BROWN
RED
WHITE
BLUE
WHITE
BLACK
BROWN
WHITE
WHITE
VIOLET
BLACK
BLACK
NOTE: The complete Part or Identifying Number (PIN) requires a color code designator (see table I).
FIGURE 1. Cable configuration.
AMSC N/A
FSC 6145
