MIL-DTL-27072/48C
REQUIREMENTS:
Design and construction:
See figure 1
Number of conductors:
3
200 °C
Temperature rating:
Components:
Basic wire:
SAE AS22759/11-20* or NEMA HP3-EWBGE* (see table I)
Conductor:
Silver coated copper
Primary insulation:
Polytetrafluoroethylene
Colors:
Black
Blue
Yellow
Jacket over Insulation:
Not applicable
Filler:
Not applicable
Lay
Not applicable
Cabling:
Not applicable
Binder tape material:
Not applicable
Shield:
Silver coated copper
Braid angle:
20 to 40 degrees
Jacket undershield:
Not applicable
Sheath:
Material:
Fluorinated ethylene propylene
Wall thickness:
.014 inch (.36 mm) nominal
Tensile strength:
In accordance with MIL-DTL-27072
Ultimate elongation:
In accordance with MIL-DTL-27072
Accelerated aging:
Not applicable
Color:
See MIL-DTL-27072
Finished cable:
See table I
Cold bend:
Mandrel size in accordance with MIL-DTL-27072
Dielectric withstanding voltage:
2,000 V rms
Conductor resistance:
In accordance with basic wire specification
TABLE I. Construction data.
Basic wire except color(reference)
Finished
SAE AS22759/11-20* 1/
cable
or NEMA HP3-EWBGE*
diameter
PIN M27072/48
Nominal
Wire
inch (mm)
Number of
Strand size
diameter
size
±10%
strands
(AWG)
Inch (mm)
JDDD
20
19
32
.058 (1.47)
.170 (4.32)
1/ SAE AS22759/11-20* color code is in accordance with MIL-STD-681.
Asterisks (*) shall be replaced by the appropriate color designator.
2
