MIL-DTL-27072/44C
Design and construction:
See figure 1
Number of conductors:
2
105 °C
Temperature rating:
Components:
Basic wire:
M16878/17BFB*** (see table I)
Conductor:
Tinned copper
Primary insulation:
Polyvinyl chloride
Colors:
Black
Red
Jacket over Insulation:
Polyamide
Color:
Natural
Filler:
Material:
In accordance with MIL-DTL-27072
Lay:
1.25 inches maximum
Cabling:
Not applicable
Binder tape material:
Polyethylene terephthalate
Shield:
Not applicable
Jacket undershield:
Not applicable
Sheath:
Polyvinyl chloride
Wall thickness:
.025 inch nominal
Tensile strength:
In accordance with MIL-DTL-27072
Ultimate elongation:
In accordance with MIL-DTL-27072
Accelerated aging:
In accordance with MIL-DTL-27072
Color:
See MIL-DTL-27072
Finished cable:
See table I
Cold bend:
Mandrel size in accordance with MIL-DTL-27072
Dielectric withstanding voltage:
2,000 V rms
Conductor resistance:
In accordance with basic wire specification
TABLE I. Construction data.
Basic wire except color
Finished
1/,2/
M16878/17BFB***
cable
(reference)
diameter
PIN 27072/44
Wire
Nominal
inch (mm)
Number of
Strand size
size
diameter
±10%
strands
(AWG)
inch (mm)
MAAA*
22
7
30
.056(1.42)
.165(4.19)
1/ Asterisks (*) shall be replaced by the appropriate color designator.
2/ Dimensions are in inches. Metric equivalents are given for information only.
2
