MIL-DTL-27072/28D
Design and construction:
See figure 1
Number of conductors:
2
105 °C
Temperature rating:
Components:
Basic wire:
M16878/17BGB*** (see table I)
Conductor:
Tinned copper
Primary insulation:
Polyvinyl chloride
Colors:
Red
White
Jacket over Insulation:
Polyamide
Color:
Natural
Filler:
Material:
In accordance with MIL-DTL-27072
Lay:
1.0 inches maximum
Cabling:
Not applicable
Binder tape material:
Not applicable
Shield:
Material:
Tinned copper
Gauge:
36 AWG
Braid angle:
20 to 40 degrees
Jacket undershield:
Not applicable
Sheath:
Material:
Polyvinyl chloride
Wall thickness:
.030 inch nominal
Tensile strength:
In accordance with MIL-DTL-27072
Ultimate elongation:
In accordance with MIL-DTL-27072
Accelerated aging:
In accordance with MIL-DTL-27072
Color:
See MIL-DTL-27072
Finished cable:
See table I
Cold bend:
Mandrel size in accordance with MIL-DTL-27072
Dielectric withstanding voltage:
2,000 V rms
Conductor resistance:
In accordance with basic wire specification
TABLE I. Construction data.
Basic wire except color
Finished
1/,2/
M16878/17BGB***
cable
(reference)
diameter
PIN 27072/28
Wire
Nominal
inch (mm)
Number of
Strand size
size
diameter
±10%
strands
(AWG)
inch (mm)
KACA*
20
7
28
.064(1.63)
.207(5.26)
1/ Asterisks (*) shall be replaced by the appropriate color designator.
2/ Dimensions are in inches. Metric equivalents are given for information only.
