MIL-DTL-27072/1C
Design and construction:
See figure 1
Number of conductors:
3
105 °C
Temperature rating:
Components:
Basic wire:
M16878/17BJE*** (See table I.)
Conductor:
Tinned copper
Primary insulation:
Polyvinyl chloride
Colors:
Black
Green
White
Jacket over insulation:
Polyamide
Color:
Natural
Filler:
Material:
In accordance with MIL-DTL-27072
Lay:
3.0 inches
Cabling:
Not applicable
Binder tape material:
Polyvinyl chloride
Shield:
Not applicable
Jacket undershield:
Not applicable
Sheath:
Material:
Polyvinyl chloride
Wall thickness:
.035 inch nominal
Tensile strength:
In accordance with table V of MIL-DTL-27072
Ultimate elongation:
In accordance with table V of MIL-DTL-27072
Accelerated aging:
In accordance with table V of MIL-DTL-27072
Color:
See table IV of MIL-DTL-27072
Finished cable:
See table I
Cold bend:
Mandrel size in accordance with table XIII of MIL-DTL-27072
Dielectric withstanding voltage:
2,000 V rms
Conductor resistance:
In accordance with basic wire specification
Table I. Construction data.
Basic wire except color
M16878/17 BJE***
Finished
(reference)
cable
PIN 27072/1
diameter
Wire
Nominal
(in.) ±10%
size
Number of
diameter
(AWG)
strands
Strand size
(inch)
FAAA*
16
19
29
.086
.266
Asterisks (*) shall be replaced by the appropriate color designator.
