MIL-DTL-25136B
3.2.3 Elongation. The elongation in 10 inches (254.00 mm) shall not be more than 1.5%.
3.2.4 Bending. The wire shall not fracture or split on the outside of the bent portion when bent flat on
itself.
3.2.5 Torsion. The wire shall be capable of withstanding at least 45 complete twists in one direction
in a 6 inch (152.40 mm) length without breaking when tested as specified herein.
3.2.6 Electrical resistance. The dc resistance per 1,000 feet at 20 șC shall not exceed the following
values:
Maximum resistance (Ω)
Type
W-106
17.9
W-106-A
24.2
3.3 Workmanship. The wire shall be uniform in properties and shall be free from pits, die marks,
rust, excessive scale, scrapes, splits, laps, cracks, seams, and other defects. The wire shall not be wavy
or kinked.
3.4 Recycled, recovered, or environmentally preferable materials. Recycled, recovered, or
environmentally preferable materials should be used to the maximum extent possible, provided that the
material meets or exceeds the operational and maintenance requirements, and promotes economically
advantageous life-cycle costs.
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as
conformance inspection (see 4.4).
4.2 Inspection conditions. Unless otherwise specified (see 6.2), all inspections shall be conducted at
a temperature of 25 șC ± 10 șC.
4.3 Requirements cross-reference matrix. Table I provides a cross-reference matrix of section 3
requirements tested or verified herein.
TABLE I. Requirements cross-reference matrix.
Inspection
Requirement
Verification
Material
Diameter
Tensile
Elongation
Bending
Torsion
Electrical resistance
Workmanship
2
