INCH-POUND
MIL-DTL-25038/3E
15 February 2011
SUPERSEDING
MIL-DTL-25038/3D
1 December 2000
DETAIL SPECIFICATION SHEET
WIRE, ELECTRICAL, HIGH TEMPERATURE, FIRE RESISTANT,
FLIGHT CRITICAL, LIGHT WEIGHT, SMALL DIAMETER
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-25038.
NICKEL COATED COPPER CONDUCTOR
(AWG 12 THROUGH AWG 18)
NICKEL COATED HIGH STRENGTH COPPER
CONDUCTOR (AWG 20 AND AWG 22)
INSULATION, INORGANIC BARRIER OR
EXTRUDED SILICONE RUBBER
INNERWRAP - IMPREGNATED, INORGANIC,
FIBROUS INSULATION
PRIMARY INSULATION - COMPOSITE
MOISTURE/MECHANICAL BARRIER
OUTER BRAID - TAPED AND FUSED
PTFE JACKET
FIGURE 1. Wire electrical.
AMSC N/A
FSC 6145
