MIL-DTL-24643/46F
TABLE I. Details.
Overall diameter
Military part no.
Type and size
Number of pairs
min.
max.
M24643/46
(inch)
(inch)
-01UO
LS2WAU-40
40
1.320
1.370
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
Conductor resistance (ohms/1000 feet at 25 °C, max.)
17.71
Voltage withstand (volts, root mean square, min.)
Conductor to conductor
2500
Conductor to overall shield
2500
Insulation resistance (megohms/1000 feet, min.)
Conductor to conductor
500
Conductor to overall shield
500
Conductor continuity
No failure
Shield continuity
No failure
Jacket flaws
No failure
Group A:
Visual and dimensional
No failure
Capacitance
Mutual capacitance, at1 kilohertz (KHz) (pF/ft, max.)
30
Watertightness (see MIL-DTL-24643 for limits of water leakage)
No failure
Group B:
Cold bending cable
No failure
Thermoset proof test (percent, max.)
Insulation
50
Jacket (when tested at 200 °C)
50
Drip (95±1°C)
Physicals (unaged)
Insulation (extruded)
2
