MIL-DTL-24643/44F
TABLE I. Details.
Overall diameter
Military part no.
Number of
Type and size
M24643/44
triads
min. (inch)
max. (inch)
-01UN
LS3SF-7
7
1.000
1.040
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
Conductor resistance (ohms/1000 feet at 25 °C, max.)
7.06
Voltage withstand (volts, root mean square, min.)
Conductor to conductor
2000
Conductor to shield
1000
Component shield to component shield
500
Insulation resistance (megohms/1000 feet, min.)
Conductor to conductor
500
Conductor to shield
500
Component shield to component shield
100
Conductor continuity
No failure
Shield continuity
No failure
Group A:
Visual and dimensional
No failure
Capacitance
Mutual capacitance, 1 kilohertz (KHz) (pF/ft, max.)
30
Capacitance unbalanced (percent max.)
10
Group B:
Thermoset proof test (percent, max.)
Insulation
50
Jacket (when tested at 200 °C)
50
Cold bending cable at minus 30±2 °C
No failure
Bending endurance at 25±2 °C (cycles, min.)
25
Physicals (unaged)
Insulation (extruded)
2
