MIL-DTL-24643/29E
TABLE I. Details (shielded and unshielded).
Overall diameter
Military part no.
Number of
Type and size
min.
max.
M24643/29
conductors
(inch)
(inch)
-01UN
LSMU-14
14
0.365
0.400
-01UD
LSMUS-14
14
0.425
0.460
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
Conductor resistance (ohms/1000 feet at 25 °C, max.)
10.93
Voltage withstand (volts, root mean square, min.)
Conductor to conductor
2000
Conductor to overall shield (Type LSMUS only)
1000
Overall shield to overall shield (Type LSMUS only)
200
Insulation resistance (megohms/1000 feet, min.)
Conductor to conductor
2000
Conductor to overall shield (Type LSMUS only)
2000
Overall shield to overall shield (Type LSMUS only)
100
Conductor continuity
No failure
Shield continuity (LSMUS only)
No failure
Jacket flaws (LSMUS only)
No failure
Group A:
Visual and dimensional
No failure
Group B:
Cold bending cable
No failure
Thermoset proof test (percent, max.)
Insulation
50
Jacket (when tested at 200 °C)
50
Physicals (unaged)
Insulation (extruded)
Tensile strength (lb/in2, min.)
700
Elongation (percent, min.)
150
2
