MIL-DTL-24643/27F
TABLE I. Details.
Overall diameter
Diameter over
Military part no.
Number of
shielded core
Type and size
min.
max.
M24643/27
pairs
nom. (inch)
(inch)
(inch)
-01UO
LS2AU-40
40
1.089
1.320
1.370
-01UD
LS2AUS-40
40
1.120
1.380
1.430
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
Conductor resistance (ohms/1000 feet at 25 °C, max.)
17.71
Voltage withstand (volts, root mean square, min.)
Conductor to conductor
2500
Overall shield to overall shield (Type LS2AUS only)
200
Insulation resistance (megohms/1000 feet, min.)
Conductor to conductor
5000
Overall shield to overall shield (Type LS2AUS only)
100
Conductor continuity
No failure
Shield continuity
No failure
Jacket flaws
No failure
Group A:
Visual and dimensional
No failure
Capacitance, at 1 megahertz (MHz) (pf/ft max.)
Mutual capacitance
20
Group B:
Cold bending cable at 0±2 °C, (16-inch mandrel diameter)
No failure
Thermoset proof test (percent, max.)
Insulation
50
Jacket (when tested at 200 °C)
50
Physicals (unaged)
Insulation (extruded)
Tensile strength (lb/in2, min.)
700
Elongation (percent, min.)
150
2
