MIL-DTL-24643/10D
TABLE I. Details.
Overall diameter
Military part
Type and size
Number of pairs
min.
max.
no. M24643/10
(inch)
(inch)
-01UN
LSPBTMU-5
5
0.499
0.540
-02UN
LSPBTMU-15
15
0.694
0.750
-03UN
LSPBTMU-30
30
0.907
0.980
REQUIREMENTS:
Qualification required.
INSPECTION:
Basic Electricals:
ANSI MC96.1 calibration limits of error
±1 °C
Voltage withstand (volts, root mean square, min.)
Conductor to conductor
1000
Insulation resistance (megohms/1000 feet, min.)
Conductor to conductor
100
Conductor continuity
No failure
Group A:
Visual and dimensional
No failure
Watertightness (see MIL-DTL-24643 for limits of water leakage)
No failure
Group B:
Cold bending cable
No failure
Thermoset proof test (percent, max.)
Insulation
50
Jacket (when tested at 200 °C)
50
Drip (95±1 °C)
Zero
Physicals (unaged)
Insulation (extruded)
Tensile strength (lb/in2, min.)
700
Elongation (percent, min.)
150
Jacket (cable)
Tensile strength (lb/in2, min.)
1300
Elongation (percent, min.)
160
2
