MIL-DTL-24640/8E
TABLE I. Construction details.
Cable diameter
Jacket
Cable weight
PIN
Type
Number of
(inch)
thickness
(pounds per 1000
M24640/8
number
component
(inch) (min.)
feet) (max.)
(min.)
(max.)
118.0
0.377
0.349
0.038
10
MXO-10
-01UO
147.0
0.410
0.380
0.041
14
MXO-14
-02UO
119.0
0.380
0.350
0.038
10
MXOW-10
-03UO
147.0
0.415
0.380
0.041
14
MXOW-14
-04UO
REQUIREMENTS:
Qualification required.
Construction details: See table I.
Component wire: The component wire shall be in accordance with SAE-AS81044 and shall be tested in
accordance with the following wire ratings and additional requirements.
Temperature rating
150 °C (302 °F) (max.) conductor temperature
Voltage rating
600 volts (root mean square) at sea level
Accelerated aging
Non-blocked
Oven temperature, 300±2 °C (572±3.6 °F) for 6 hours
Water-blocked
Oven temperature, 250±2 °C (482±3.6 °F) for 6 hours
Blocking
150±2 °C (302±3.6 °F)
Flammability
30 seconds (max.)
3.0 inches (max.)
No flaming of tissue paper
Humidity resistance
5000 megohms for 1000 feet (min.) insulation resistance after
humidity exposure
Dielectric test (100% test)
Primary insulation
Impulse test - 6.0 kV (peak) or 3 kHz spark test - 1.5kV root
mean square
Component wire
Impulse test - 8.0 kV (peak) or 3 kHz spark test - 5.5kV root
mean square
Insulation resistance
5000 megohms for 1000 feet (min.)
Life cycle
Non-blocked
Oven temperature, 200±2 °C (392±3.6 °F) for 168 hours
Water-blocked
Oven temperature, 200±2 °C (392±3.6 °F) for 120 hours
Physical properties of primary insulation
2500 lb/in2 (min.)
Tensile strength
2
