INCH-POUND
MIL-DTL-24640/1E
8 November 2011
SUPERSEDING
MIL-DTL-24640/1D
22 August 2002
DETAIL SPECIFICATION SHEET
CABLE, ELECTRIC, -20 TO +105 °C, 600 VOLTS, LIGHTWEIGHT, TWO-CONDUCTOR,
LOW POWER, TYPES DX AND DXWB
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-24640.
Construction, Non-Watertight (DX) and Watertight (DXWB)
First
19-strand, tin-coated copper conductor and AWG size in accordance with table I.
-
Watertight constructions shall be constructed with 7 strands.
Second
Component wires shall be SAE-AS81044/12, except identification shall be in accordance
-
with the codes and methods of MIL-DTL-24640. Testing shall be done in accordance
with the component wire ratings and requirements listed on this specification sheet.
Conformance testing shall be in accordance with SAE-AS81044 prior to cabling.
Identification codes applied using Method 1 or 3. If Method 1 is used, component wire
shall be white.
Third
Two component wires cabled together.
-
Fourth
Optional binder tape.
-
Cross-linked polyolefin jacket (see table I for thickness).
Fifth
-
NOTE: Manufacturer's identification tape or thread is required (see 3.7.3).
TABLE I. Construction details.
Cable diameter
Cable weight
Conductor
Jacket
(inch)
(pounds per
resistance
Type
AWG
PIN M24640/1
thickness
number
size
1000 feet)
per 1000
(inch) (min.)
(min.)
(max.)
(max.)
feet (ohms)
4.98
39.4
0.241
0.223
0.031
16
DX-3
-01UN
3.18
56.8
0.286
0.266
0.034
14
DX-4
-02UN
4.33
45.4
0.251
0.233
0.031
16
DXWB-3
-03UN
2.78
67.8
0.296
0.276
0.034
14
DXWB-4
-04UN
AMSC N/A
FSC 6145
