MIL-DTL-22931/9A
REQUIREMENTS:
Operating temperature range: -55 to +80°C.
Inner conductor: See table II.
Dielectric:
Cable core and insulating layer: See table II.
Outer conductor: Aluminum tubing, smooth, seamless.
Diameters See table II.
Jacket: See table II.
Voltage withstand: 1,800 volts rms (minimum) at 60 Hz, or 3,200 volts dc.
Insulation defects, spark: See table II.
Attenuation: See table II.
Velocity: See table.
Capacitance: 24.0 pf/ft.
Impedance: 50 ± 2 ohms.
Voltage standing wave ratio: See Table I.
TABLE I. Initial and Final Frequency Ranges.
Frequency
Initial
After bending and
range
temperature cycling
(MHz)
(max)
(max)
500 2,000
1.15
1.18
2,000 5,000
1.20
1.25
5,000 10,000
1.20
1.25
Mandrel size for cold bend, bending and temperature cycling tests: 15 inches (381.0 mm).
Minimum bending radius: 5 inches (127.0 mm).
3
