MIL-DTL-22931/17A
TABLE II. Characteristics. 1/
Requirement 2/
PIN M22931/17-001
Inner conductor
Silver plated
Overall diameter ± 0.002 (0.05) Copper wire 0.153 (3.89)
Dielectrics
Polytetra-
Cable Core
fluorethylene
Outer conductor diameter
Inside (nominal)
0.421 (10.69)
Outside
0.495 (12.57)
Attenuation (dB/100 ft max)
30 MHz
0.48
400 MHz
2.10
3,000 MHz
6.90
Velocity (percent)
85.0
1/ Dimensions are in inches. Metric equivalents are given for information only.
2/ The following requirements of MIL-DTL-22931, identified by similarity of paragraph
headings, are not applicable to this slash sheet: insulation resistance, pressure tightness,
and marking.
Cross reference information: See table III.
TABLE III. Cross reference information.
PIN
RG cable number
M22931/17-001 RG-385/U
Attenuation and power rating: See figures 1 and 2.
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
Referenced documents. This document references MIL-DTL-22931.
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Army CR
DLA-CC
Navy - EC
Air Force - 85
DLA -CC
(Project 6145-2013-005)
Review activities:
Army AT, CR4, MI
Navy AS, MC, OS
Air Force 19
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above
using the ASSIST Online database at https://assist.dla.mil.
