MIL-DTL-17/60D
TABLE I. Description.
Components
Construction details
Inner conductor
Solid silver-coated, steel wire
Overall diameter: 0.037 inch ± 0.001
Dielectric core
Type F-1: Solid, extruded PTFE
Diameter: 0.116 inch ± 0.005
Double braid of AWG #36 silver-coated copper wire
Outer conductor
Diameter: 0.171 inch maximum
Coverage: 94.8% nominal
Inner braid
Carriers: 16
Ends: 7
Picks/inch: 11.5 ± 10%
Outer braid
Coverage: 93.1% nominal
Carriers: 16
Ends: 7
Picks/inch: 14.5 ± 10%
Jacket
Type IX: FEP
Diameter: 0.195 inch ± 0.005
ENGINEERING INFORMATION
Configuration: See figure 1.
Capacitance: 29.3 pF per foot, nominal.
Continuous working voltage: 1,400 V rms, maximum.
Operating frequency: 12.4 GHz, maximum.
Velocity of propagation: 69.5 percent, nominal.
Power rating: See figure 2.
Operating temperature range: -55° to +200°C.
Weight: 0.043 pound per foot, nominal.
Inner conductor properties:
DC resistance (maximum at 20°C): 1.95 ohms per 100 feet.
Elongation: 1 percent, minimum.
Tensile strength: 110 klbf/inch2, minimum.
Engineering notes: This cable useful in general purpose, high temperature applications. (See
connector series "TNC", "BNC", and "SMA" in accordance with MIL-PRF-39012. NATO preferred
type NWR-25.)
