MIL-DTL-17/2B
TABLE II. Description.
Components
Construction details
Inner conductor
Solid, copper-covered, steel wire
Overall diameter: 0.0285 inch ± 0.0010
Dielectric core
Type A-1: Solid, polyethylene
Diameter: 0.185 inch ± 0.004
Outer conductor
Double braid of AWG #34 copper wire
Diameter: 0.264 inch maximum
Alternates
Inner braid
Wire coating:
Silver-coated
Silver-coated
Coverage:
95.0% nominal
95.0% nominal
Carriers:
16
24
Ends:
9
6
5.9 ± 10%
Picks/inch:
8.8 + 10%
Outer braid
Wire coating: Bare
Bare
Coverage:
95.0% nominal
95.0% nominal
Carriers:
16
24
Ends:
9
6
8.7 ± 10%
Picks/inch:
13.0 + 10%
Jacket
Type IIa: PVC
Diameter: 0.332 inch ± 0.004
ENGINEERING INFORMATION
Continuous working voltage: 2,000 V rms, maximum.
Operating frequency: 3 GHz, maximum.
Velocity of propagation: 65.9 percent, nominal.
Power rating: See figure 2.
Operating temperature range: -40°C to +85°C.
Weight: 8.2 pounds per 100 feet, maximum.
Inner conductor properties:
DC resistance (maximum at 20°C): 4.4 ohms per 100 feet.
Elongation: 30 percent, minimum.
2
Tensile strength: 115 klbf/inch , minimum.
Engineering notes: This cable useful in low temperature applications. (See connector series "N" and
"SC" as specified in MIL-PRF-39012.)
