MIL-DTL-17/188C
TABLE I. Description Continued.
Components
Construction details
Barrier tape A .001 inch thick polyester tape faced with a .002 inch thick layer of aluminum. The tape will be
applied with a 50% lap, aluminum face toward the outer conductor. Diameter: .265 inch
maximum.
Jacket
Cross-linked polyolefin. Diameter: .332 inch ± .004.
REQUIREMENTS:
Continuous working voltage: 2,200 V rms, maximum.
Operating frequency: 11 GHz, maximum.
Velocity of propagation: 65.9 percent, nominal.
Power ratings: See figure 2.
Operating temperature range: -30°C to +85°C.
Inner conductor properties:
DC resistance (maximum at +20°C): 0.348 ohms per 100 feet.
Elongation: 25 percent, minimum.
Dimensions, configuration, and descriptions: See figure 1 and table I.
Environmental and mechanical:
Visual and mechanical examination: Applicable.
Out-of-roundness: Not applicable.
Eccentricity: 10 percent maximum.
Adhesion of conductors:
Inner conductor to core: 5 pounds, minimum; 45 pounds, maximum.
Aging stability: +98°C ± 2°C.
Cold bend: -30°C ± 2°C.
Dimensional stability: +85°C ± 2°C.
Inner conductor from core: .062 inch, maximum.
Inner conductor from jacket: .125 inch, maximum.
Contamination: Not Applicable.
Flame propagation: Applicable.
Acid gas generation: 2.0 percent, maximum.
2
