MIL-DTL-17/184C
TABLE I. Description.
Component
Construction
Inner conductor
Solid copper- covered steel wire.
Overall diameter: .0226 inch ±0.0010
Dielectric core
Type A-1: Solid, polyethylene.
Diameter: .146 inch ±0.004
Outer conductor
Single braid of AWG No. 34, bare copper wire
Diameter: .182 inch maximum
Alternate
Coverage:
94.4% nominal
Coverage:
96.7% nominal
Carriers:
16
Carriers:
24
Ends:
7
Ends:
5
Picks/inch:
8.2 ±10%
Picks/inch:
12.3 ±10%
Barrier tape
A .001 inch thick polyester tape faced with a .002 inch thick layer of aluminum.
The tape shall be applied with a 50% lap, aluminum face toward the outer
conductor.
Diameter: .192 inch maximum
Jacket
Cross-linked polyolefin
Diameter: .242 inch ±0.004
ENGINEERING INFORMATION
Continuous working voltage: 1,700 V rms, maximum.
Operating frequency: 1GHz, maximum.
Velocity of propagation: 65.9 percent, nominal.
Power rating: See figure 2.
Operating temperature range: -30°C to +85°C.
Inner conductor properties:
DC resistance (maximum at +20°C): 4.8 ohms per 100 feet.
Elongation: 1 percent, minimum.
2
Tensile strength: 110klbf/inch , minimum.
Engineering note: This cable is useful in low temperature applications.
(See connector series "BNC" and "TNC" in accordance with MIL-PRF-39012.)
