MIL-DTL-17/158B
TABLE I. Description.
Component
Construction details
Inner conductor
Solid silver-coated, copper-covered steel wire.
Overall diameter: 0.037 inch ± 0.001
Dielectric core
Type F-1: Solid extruded PTFE
Diameter: 0.116 Inch ± .005
Outer conductor
Double braid of AWG No. 36 silver-coated copper wire.
Diameter: 0.171 inch maximum
Inner braid
Coverage: 94.8% nominal
Carriers: 16
Ends: 7
Picks/inch: 11.5 ± 10%
Outer braid
Coverage: 93.1% nominal
Carriers: 16
Ends: 7
Picks/inch: 14.5 ± 10%
Jacket
Type IX: FEP
Diameter: 0.195 inch ± 0.005
CAUTION IS DIRECTED TO THE APPLICATION OF THIS CABLE ABOVE 400 MHz.
ATTENUATION IS TESTED ONLY AT 400 MHz. SRL AND POWER HANDLING CAPABILITIES ARE
NOT STIPULATED HERElN.
ENGINEERING INFORMATION
Continuous working voltage: 1,400 V rms, maximum.
Velocity of propagation: 69.5 percent, nominal.
Operating temperature range: -55°C to +200°C.
Inner conductor properties:
DC resistance (maximum at 20°C): 1.95 ohms per 100 feet.
Elongation: 1 percent, minimum.
Tensile strength: 110 klbf/inch2, minimum.
Engineering note: This cable is useful in general purpose, high temperature applications. (See
connector series "TNC", "BNC", and "SMA" in accordance with MIL-PRF-39012.)
