MIL-DTL-17/129E
Return
Reflection
loss
SWR
coefficient
dB
.8913
1
17.3910
.7943
2
8.7242
.7079
3
5.8480
.6310
4
4.4194
.5623
5
3.5698
.5012
6
3.0095
.4467
7
2.6146
.3981
8
2.3229
.3548
9
2.0999
.3162
10
1.9250
.2818
1.7849
11
.2512
1.6709
12
.2239
1.5679
13
.1995
1.4985
14
.1778
1.4326
15
.1585
1.3767
16
.1413
1.3290
17
.1259
1.2880
18
.1122
1.2528
19
1.2222
.1000
20
1.1957
.0891
21
1.1726
.0794
22
1.1524
.0708
23
1.1347
.0631
24
1.1192
.0562
25
1.1055
.0501
26
1.0935
.0447
27
1.0829
.0398
28
1.0736
.0355
29
1.0653
.0316
30
FIGURE 3. Structural return loss - Continued.
