MIL-DTL-16878/33B
TABLE I. Wire configuration and dimensions.
Finished wire
Polyamide
Conductor
Conductor
diameter
thickness
Wire
diameter
1/
PIN
Stranding
(inch)
(inch)
size
(nominal)
Material 2/
Min
Max
Min
Max
Coating
(inch)
M16878/33BEA*
24
1 X 24
Copper
Tin
.0201
.045
.057
.002
.004
24 3/
M16878/33CEA*
1 X 24
C.C. steel
Tin
.0201
.045
.057
.002
.004
M16878/33BEB*
24
7 X 32
Copper
Tin
.0240
.049
.061
.002
.004
M16878/33BEE*
24
19 X 36
Copper
Tin
.0250
.049
.061
.002
.004
22 3/
M16878/33BFA*
1 X 22
Copper
Tin
.0254
.051
.064
.002
.004
M16878/33CFA*
22
1 X 22
C.C. steel
Tin
.0254
.051
.064
.002
.004
M16878/33BFB*
22
7 X 30
Copper
Tin
.0300
.056
.068
.002
.004
M16878/33BFE*
22
19 X 34
Copper
Tin
.0320
.056
.068
.002
.004
M16878/33BGA*
20
1 X 20
Copper
Tin
.0320
.060
.072
.002
.004
M16878/33BGB*
20
7 X 28
Copper
Tin
.0380
.066
.078
.002
.004
M16878/33BGE*
20
19 X 32
Copper
Tin
.0400
.066
.078
.002
.004
M16878/33BHA*
18
1 X 18
Copper
Tin
.0403
.068
.081
.002
.004
M16878/33BHB*
18
7 X 26
Copper
Tin
.0480
.076
.088
.002
.004
M16878/33BHE*
18
19 X 30
Copper
Tin
.0500
.076
.088
.002
.004
M16878/33BHD*
18
16 X 30
Copper
Tin
.0470
.075
.087
.002
.004
M16878/33BRL*
4
33 X 25
Copper
Tin
.2690
.349
.363
.007
.014
M16878/33BSL*
2
33 X 23
Copper
Tin
.3350
.413
.443
.007
.014
M16878/33BTN*
1
59 X 25
Copper
Tin
.3780
.461
.493
.007
.014
M16878/33BUN*
0
59 X 24
Copper
Tin
.4240
.509
.539
.007
.014
M16878/33BWN*
00
59 X 23
Copper
Tin
.4770
.579
.613
.007
.014
M16878/33BZN*
0000
59 X 21
Copper
Tin
.6010
.704
.738
.007
.014
Notes:
1/ PIN stands for part or identifying number (see figure 2).
2/ C.C. stands for copper-clad.
3/ Inactive for new design.
2
