MIL-DTL-16878/19B
TABLE I. Wire configuration and dimensions - Continued.
Finished wire
Polyamide
Conductor
diameter
thickness
Diameter
Conductor
Wire
PIN 1/
Stranding
(inch)
(inch)
size
(nominal)
2/, 3/
Material
(inch)
Min
Max
Min
Max
Coating
M16878/19BKA*
14
1 X 14
Copper
Tin
.0641
.121
.142
.0030
.006
M16878/19BKE*
14
19 X 27
Copper
Tin
.0720
.129
.150
.0030
.006
M16878/19BKH*
14
41 X 30
Copper
Tin
.0800
.137
.158
.0030
.006
M16878/19BLA*
12
1 X 12
Copper
Tin
.0808
.159
.171
.0030
.006
M16878/19BLE*
12
19 X 25
Copper
Tin
.0920
.162
.183
.0030
.006
M16878/19BLG*
12
37 X 28
Copper
Tin
.0890
.159
.180
.0030
.006
M16878/19BLJ*
12
65 X 30
Copper
Tin
.0980
.168
.189
.0030
.006
M16878/19BMA*
10
1 X 10
Copper
Tin
.1019
.174
.197
.0040
.008
M16878/19BMG*
10
37 X 26
Copper
Tin
.1110
.183
.206
.0040
.008
M16878/19BMK*
10
105 X 30
Copper
Tin
.1270
.199
.222
.0040
.008
M16878/19BNL*
8
133 X 29
Copper
Tin
.1690
.253
.280
.0060
.012
M16878/19BPL*
6
133 X 27
Copper
Tin
.2130
.300
.329
.0070
.014
M16878/19BRL*
4
133 X 25
Copper
Tin
.2680
.362
.396
.0070
.014
M16878/19BSP*
2
665 X 30
Copper
Tin
.3420
.436
.470
.0070
.014
M16878/19BTR*
1
817 X 30
Copper
Tin
.3820
.486
.520
.0070
.014
M16878/19BUS*
0
1045 X 30
Copper
Tin
.4310
.525
.545
.0070
.014
Notes:
1/ PIN stands for part or identifying number (see figure 2).
2/ H.S.C.A. stands for high-strength copper alloy.
3/ C.C. stands for copper-clad.
