MIL-DTL-16878/14B
TABLE I. Wire configuration and dimensions.
Finished wire
Conductor
Conductor
diameter
diameter
Wire
1/
PIN
Stranding
(inch)
(nominal)
size
(inch)
Material
Coating
Min
Max
M16878/14BAA*
32
1 X 32
Copper
Tin
.0080
.024
.030
M16878/14BAB*
32
7 X 40
Copper
Tin
.0100
.026
.032
M16878/14BBA*
30
1 X 30
Copper
Tin
.0100
.026
.032
M16878/14BBB*
30
7 X 38
Copper
Tin
.0120
.028
.034
M16878/14BCA*
28
1 X 28
Copper
Tin
.0126
.029
.035
M16878/14BCB*
28
7 X 36
Copper
Tin
.0150
.031
.037
M16878/14BDA*
26
1 X 26
Copper
Tin
.0159
.032
.038
M16878/14BDB*
26
7 X 34
Copper
Tin
.0190
.035
.041
M16878/14BDE*
26
19 X 38
Copper
Tin
.0200
.035
.041
M16878/14BEA*
24
1 X 24
Copper
Tin
.0201
.036
.044
M16878/14BEB*
24
7 X 32
Copper
Tin
.0240
.040
.047
M16878/14BEE*
24
19 X 36
Copper
Tin
.0250
.040
.047
M16878/14BFA*
22
1 X 22
Copper
Tin
.0254
.041
.0499
M16878/14BFB*
22
7 X 30
Copper
Tin
.0300
.046
.053
M16878/14BFE*
22
19 X 34
Copper
Tin
.0320
.046
.053
M16878/14BGA*
20
1 X 20
Copper
Tin
.0320
.048
.055
M16878/14BGB*
20
7 X 28
Copper
Tin
.0380
.054
.061
M16878/14BGE*
20
19 X 32
Copper
Tin
.0400
.054
.061
M16878/14BHA*
18
1 X 18
Copper
Tin
.0403
.056
.064
M16878/14BHB*
18
7 X 26
Copper
Tin
.0480
.064
.071
M16878/14BHE*
18
19 X 30
Copper
Tin
.0500
.064
.071
M16878/14BJA*
16
1 X 16
Copper
Tin
.0508
.067
.075
M16878/14BJE*
16
19 X 29
Copper
Tin
.0570
.073
.081
M16878/14BKA*
14
1 X 14
Copper
Tin
.0641
.080
.088
M16878/14BKE*
14
19 X 27
Copper
Tin
.0720
.088
.096
Notes:
1/ PIN stands for part or identifying number (see figure 2).
M16878/
14
B
F
E
*
Military designation
Specification sheet
Conductor
Conductor
Conductor
Color
material
size
stranding
code
FIGURE 2. Example of PIN (see MIL-DTL-16878G).
2
