MIL-DTL-13486E
OPENING FOR CUTTING
INSULATED CONDUCTOR
END TO BE
CLAMPED
6
Inche
mm
s
3
76.2
6
152
3
LOOSE, INSULATED
CONDUCTORS
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
FIGURE 2. Preparation of sample for longitudinal shifting test.
