FED-STD-228A
5.2 Unless otherwise specified in the detail specification, the number of specimens tested from each
inspection unit shall be as required in the method of test, 4.2, used for determining the deterioration of the
insulation or sheath.
5.3 The change in the characteristic of the insulation or sheath of the inspection unit shall be recorded to
the nearest one percent.
5.4 The temperature, pressure, and time of exposure used shall be recorded.
6" Rad.
SAFETY BLOW-OUT
LEAD OR OTHER
SATISFACTORY
RING GASKET
6" INSIDE
13.5"
DIAMETER
10"
7.5" OUTSIDE
DIAMETER
OXYGEN SUPPLY
FIGURE 4011A.
117
