FED-STD-228A
Method 2211.1
18 APRIL 2014
ABRASION RESISTANCE
1. SCOPE
1.1 This method is intended for use in determining the abrasion resistant characteristics of the finished
wire or cable.
NOTE: Intended for use with neoprene cable.
2. SPECIMEN
2.1 This specimen shall consist of 2 samples of finished insulated wire or cable. Each sample shall be
30 inches in length, minimum.
3. APPARATUS
3.1 The apparatus shall be as follows:
3.1.1 Abrasion tests (see figure 1).
4. PROCEDURE
4.1 Tow untested samples 30 inches in length, shall be mounted securely at one end and weights, as
specified in table I, freely suspended to the other end with the cable or wire placed over a squirrel cage
abrasion tester as shown on figure 1. A suitable tripping circuit shall be arranged to denote failure by
stopping the machine when any bar of the squirrel cage come in contact with the bare conductor of the
cable or wire. The specimen shall be subjected to 20 + 2 oscillations per minute. An oscillation shall
consist of 5 bars travel forward and backward from a given point.
TABLE I. Diameter under sheath and weight.
Diameter under sheath (in.)
Weight abrasion-aging
(pounds)
0.325 and less
2
0.326 to 0.430
2
0.431 to 0.540
2
0.541 to 0.640
3
0.741 to 0.850
3
0.851 to 1.100
6
1.101 to 1.320
6
1.321 to 1.550
6
1.551 to 1.820
6
5. RESULTS
5.1 Unless otherwise specified in the detail specification or specification sheet, one specimen from each
inspection unit shall be tested.
5.2 The weight used shall be recorded..
83
