MIL-DTL-27072 Cable, Power, Electrical And Cable, Special Purpose, Electrical, Multiconductor And Single Shielded, General Specification ForThis specification covers special purpose electrical multi-conductor and single shielded cable for electronic circuits where the cable will be protected in racks, tunnels, or within buildings, trailers, or equipment. Cables constructed using polyvinyl chloride \(PVC\) on insulated wires or for fillers, tapes, or jackets are not to be used for aerospace applications.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12


. . . . .
MIL-DTL-27072E
APPENDIX A
A.1 SCOPE
A.1.1 Scope. This appendix is a mandatory part of the specification. The information contained
herein is intended for informational purposes. This appendix provides a cross-reference of former basic
wire, jacket material, and sheath designators to current basic wire, jacket material, and sheath
designators.
A.2 Basic wire designator cross-reference. Cross-reference of former basic wire types and
designator to current basic wire designator (see table II) is shown in table A-I.
TABLE A-I. Cross-reference of former basic wire types and
designators to current basic wire designators.
Former basic wire
MIL-C-27072B
MIL-DTL-27072C
Basic wire specification
designator
designator
designator
MIL-DTL-16878/17
Type I
A
A
MIL-DTL-16878/18
Type II
B
B
-
Type III superseded by C superseded by H
Deleted
Type VIII
1/
MIL-W-16878/4
Type IV
D
D
1/
MIL-W-16878/21
1/
MIL-W-16878/5
Type V
E
E
1/
MIL-W-16878/22
MIL-DTL-17
Type VI
F
Deleted
MIL-W-5845
Type VII
G
Deleted
MIL-W-5846
MIL-DTL-16878/10
Type VIII
H
Deleted
MIL-DTL-16878/19
Type IX
J
Deleted
MIL-DTL-16878/2
Type XII
M
Deleted
MIL-DTL-16878/3
Type XIII
N
Deleted
MIL-DTL-16878/1
Type XIV
P
P
1/ Superseded by NEMA-HP3.
A.3 Jacket material designator cross-reference. Cross-reference of former component jacket
material class and designator to current component jacket material designator (see table I) is shown in
23
