INCH-POUND
MIL-DTL-27072/42C
12 March 2012
SUPERSEDING
MIL-DTL-27072/42B
8 December 2000
DETAIL SPECIFICATION SHEET
CABLE, SPECIAL PURPOSE, ELECTRICAL, MULTICONDUCTOR
(4 CONDUCTORS) AND SINGLE SHIELDED,
M27072/42JBCA*
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-27072.
REQUIREMENTS:
SHEATH POLYVINYL CHLORIDE
SHIELD TINNED COPPER
TAPE POLYETHYLENE
TEREPHTHALATE
BLACK
WHITE
FILLER
GREEN
RED
NOTE: The complete Part or Identifying Number (PIN) requires a color code designator (see table I).
FIGURE 1. Cable configuration.
AMSC N/A
FSC 6145
