INCH - POUND
MIL-DTL-22759/87A
23 February 1998
SUPERSEDING
MIL-W-22759/87
9 September 1994
MILITARY SPECIFICATION SHEET
WIRE, ELECTRICAL, POLYTETRAFLUOROETHYLENE/POLYIMIDE
INSULATED, NORMAL WEIGHT, NICKEL COATED, COPPER CONDUCTOR.
260°C, 600 VOLTS.
This specification sheet has been approved by all departments and agencies within the Department of
Defense; however it is not intended for use in Naval aircraft or Naval Air Systems applications.
The requirements for acquiring the product described herein shall consist of this specification sheet and the issue of
the following specification listed in that issue of the Department of Defense Index of Specifications and Standards
(DoDISS) specified in the solicitation: MIL-W-22759
FP / POLYIMIDE / FP TAPE
SIZES 26 THROUGH 10
1/
FP TAPE
FP / POLYIMIDE / FP TAPE
1/
SIZES 8 THROUGH 6
FP TAPE
FP TAPE
FP / POLYIMIDE / FP TAPE
FP TAPE
1/
SIZE 4
FP TAPE
FP - Fluorocarbon Polymer, modified Polytetrafluoroethylene (PTFE)
FIGURE 1.
General configuration.
1/
Small diameter stranded nickel coated copper conductor (sizes 26 to 4)
AMSC N/A
FSC 6145
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited
1 of 8
