U\)This specification covers 2, 3, and 4 cadmium copper alloy stranded retractile conductor electrical cords. These cords are insulated with a natural rubber compound encased in a Buna S or Buna S and natural rubber compound jacket which is vulcanized in a helical spring coil form to produce a cord which will extend and retract freely. These cords are designed for use on communications equipment at audio frequencies, with a temperature range of -0 to 60 degrees C for continuous operation.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15

INCH-POUND

MIL-DTL-13273C

01 November 2012

SUPERSEDING

MIL-DTL-13273B

14 January 2008

DETAIL SPECIFICATION

CORD, ELECTRICAL, (RETRACTILE, 2, 3, AND 4

CONDUCTOR, WD-9/U, WT-2/U, WF-4/U)

Inactive for new design after 16 June 1997.

This specification is approved for use by all Departments

and Agencies of the Department of Defense.

1. SCOPE

1.1 Scope. This specification covers 2, 3, and 4 cadmium copper alloy stranded retractile conductor

electrical cords. These cords are insulated with a natural rubber compound encased in a Buna S or Buna

S and natural rubber compound jacket which is vulcanized in a helical spring coil form to produce a cord

which will extend and retract freely. These cords are designed for use on communications equipment at

audio frequencies, with a temperature range of -0 to 60�C for continuous operation.

1.2 Classification. This specification covers the following retractile cords designated as follows:

Cordage WD-9/U (2 conductor)

Cordage WT-2/U (3 conductor)

Cordage WF-4/U (4 conductor)

2. APPLICABLE DOCUMENTS

2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this

specification. This section does not include documents cited in other sections of this specification or

recommended for additional information or as examples. While every effort has been made to ensure the

completeness of this list, document users are cautioned that they must meet all specified requirements of

documents cited in sections 3, 4, or 5 of this specification, whether or not they are listed.

Comments, suggestions, or questions on this document should be addressed to DLA Land and

Maritime Columbus, ATTN: VAI, P.O. Box 3990, Columbus, Ohio 43218-3990, or email to

WireCable@dla.mil. Since contact information can change, you may want to verify the currency of

this address information using the ASSIST Online database at https://assist.dla.mil.

AMSC N/C

FSC 6145
